This page contains the broad general technical configuration details and settings that you may need to set up your Internode services.
- NBN
- TurboFibre FTTB
- ADSL2+
- IPv6
- NodePhone VoIP
- NodeMobile
- NodeMobile Data 3G
- DNS Servers
- Other Configuration Information
The information on this page is also included, along with your username and password, in the welcome pack you would have received when you first connected to Internode.
Please contact our support team if you have any questions or need assistance.
NBN
These generic settings are suitable for most NBN technologies.
Some specific settings/requirements may apply to your broadband router for FTTN and FTTB, which are delivered using VDSL2 technology.
| NBN Username | [email protected] | ||||||||||||
| Authentication Type Encapsulation |
PPPoE | ||||||||||||
| Authentication Method | CHAP or PAP | ||||||||||||
| Connection Type For some existing customers |
|
||||||||||||
| Connection Type For all new and some existing customers |
|
||||||||||||
| VLAN ID Tag (802.1q) For some existing customers |
|
||||||||||||
| VLAN ID Tag (802.1q) For all new and some existing customers |
|
||||||||||||
| VDSL2 specific settings for NBN FTTN and FTTB |
|
NBN Configuration Guides NBN Product Information
TurboFibre FTTB
Modems must support VDSL2 and VLAN.
| Internet Service Provider (ISP) | Other (Do not select "Internode") |
| DSL Standard/Mode/Modulation | VDSL2 |
| Connection Type/Mode/WAN Type | PPPoE |
| VDSL Profile | 17a Multi Mode |
| VDSL Connection Type | PTM |
| VLAN | Enabled/on (or you may need to set the VLAN networking standard, 802.1q) |
| VLAN ID | 2 |
| VLAN 802.1p/VLAN Priority | 0 (or set VLAN Priority to Disable) |
| Username | N/A |
| Password | N/A |
| G.INP | Enabled |
| G.Vector | Enabled |
| DNS | 203.0.178.191 or 203.215.29.191 |
ADSL2+
| ADSL Username | [email protected] |
| Encapsulation | PPPoE / LLC |
| Authentication Method | CHAP or PAP |
| Supported Modulation Types | G.DMT (Standard ADSL) G.DMT.bis+ (ADSL2+) ADSL2+ Annex M (in selected areas) Multimode/Auto (Recommended) |
| VPI/VCI | 8/35 |
ADSL Configuration Guides ADSL Product Information
IPv6
| IPv6 Toolbox | go to the IPv6 toolbox |
| DNS Settings | See DNS Servers section |
| E-Mail Address | [email protected] |
| E-Mail Login Name | username |
| Incoming Mail Server (IMAP or POP3) | mail.internode.on.net |
| Outgoing Mail Server (SMTP) | mail.internode.on.net |
| Secure (SSL) Email Config | go to the secure email config |
| Webmail | https://webmail.internode.on.net |
| Spam / Virus / Forwarding Config | https://mailconfig.internode.on.net |
NodePhone VoIP
| SIP Server | sip.internode.on.net |
| SIP port | 5060 |
| NodePhone Username | NodePhone phone number |
NodePhone Configuration Guides NodePhone Product Information
NodeMobile
| APN Internet | internet (or yesinternet for iPhone and Android) |
| APN Type Internet | internet or default |
| APN MMS | mms |
| APN Type MMS | mms |
| SMSC | +61411990001 |
NodeMobile Settings FAQ NodeMobile Product Information
NodeMobile Data 3G
| APN | internode (services prior to 26/08/09 use: splns333a1) |
| SP Code | inode (services prior to 26/08/09 use: 333A1) |
| Default SIM Pin | 0000 |
| Phone Number (if required) | *99# |
NodeMobile Data Configuration Guides NodeMobile Data Product Information
DNS Servers
| Domain Name | internode.on.net |
| Primary DNS Server | 192.231.203.132 (or Auto Assigned) |
| Secondary DNS Server | 192.231.203.3 (or Auto Assigned) |
| Primary IPv6 DNS Server | 2001:44b8:1::1 (or Auto Assigned) |
| Secondary IPv6 DNS Server | 2001:44b8:2::2 (or Auto Assigned) |
Other General Information
| Home Page | www.internode.on.net |
| Proxy Server | None, direct connection to the Internet |
| Dialup Access Number | 0198 333 004 |
| NTP Server (Network Time Protocol) | ntp.internode.on.net |
| HTTP/FTP Download Mirror | http://mirror.internode.on.net |
